NLVHC1G08DTT1G
1uA 2V~6V 17ns@6.0V TSOP-5-1.5mm Gates and Inverters
TSOP-5-1.5mmRoHSDiscontinued
Single 2-Input AND Gate
- Manufacturer
- onsemi
- Manufacturer part #
- NLVHC1G08DTT1G
- Store part #
- C2983751
- Package / case
- TSOP-5-1.5mm
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,915 in stock
#C2983751
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹22.37 | ₹111.85 |
| 50+ | ₹19.71 | ₹985.50 |
| 150+ | ₹18.57 | ₹2,785.50 |
| 500+ | ₹17.16 | ₹8,580.00 |
| 3,000+ | ₹16.52 | ₹49,560.00 |
| 6,000+ | ₹16.14 | ₹96,840.00 |
5 × ₹22.37
₹111.85
excl. GST
₹131.98 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
NLVHC1G08DTT1G
₹111.85 for 5 + GST
Specifications
- Operating Temperature
- -55℃~+125℃
- Logic Family
- 74HC
- Input Logic Level - High
- 1.5V;2.1V;3.15V;4.2V
- Input Logic Level - Low
- 500mV;900mV;1.35V;1.8V
- Output Logic Level - High
- 1.9V;2.9V;4.4V;5.9V
- Quiescent Current(Iq)
- 1uA
- Voltage - Supply
- 2V~6V
- Current - Output High(IOH)
- 2.6mA
- Number of Channels
- 1;2
- Propagation Delay
- 17ns@6.0V
- Output Logic Level - Low
- 100mV;260mV
- Current - Output Low(IOL)
- 2.6mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Discontinued
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.043 g
Overview
The MC74HC1G08 is a high speed CMOS 2−input AND gate fabricated with silicon gate CMOS technology. The internal circuit is composed of multiple stages, including a buffer output which provides high noise immunity and stable output. The MC74HC1G08 output drive current is 1/2 compared to MC74HC series.
Key features
- High Speed: tpD = 7 ns (Typ) at VCC = 5 V
- Low Power Dissipation: ICC = 1 μA (Max) at TA = 25℃
- High Noise Immunity
- Balanced Propagation Delays (tpLH = tpHL)
- Symmetrical Output Impedance (IOH = IOL = 2 mA)
- Chip Complexity: < 100 FETs
- NLV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q100 Qualified and PPAP Capable
- These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
