SN74AHC1G08DBVR
Schmitt trigger 2V~5.5V 7.9ns@5V,50pF 1uA SOT-23-5 Gates and Inverters RoHS
SOT-23-5ROHS3 CompliantActive
SINGLE 2-INPUT POSITIVE-AND GATE
- Manufacturer
- TI
- Manufacturer part #
- SN74AHC1G08DBVR
- Store part #
- C7467
- Package / case
- SOT-23-5
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
55,600 in stock
#C7467
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹8.96 | ₹89.60 |
| 100+ | ₹7.26 | ₹726.00 |
| 300+ | ₹6.40 | ₹1,920.00 |
| 3,000+ | ₹5.24 | ₹15,720.00 |
| 6,000+ | ₹4.99 | ₹29,940.00 |
| 9,000+ | ₹4.82 | ₹43,380.00 |
10 × ₹8.96
₹89.60
excl. GST
₹105.73 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SN74AHC1G08DBVR
₹89.60 for 10 + GST
Specifications
- Input Type
- Schmitt trigger
- Logic Family
- 74AHC Series
- Voltage - Supply
- 2V~5.5V
- Output Logic Level - Low
- 440mV
- Propagation Delay
- 7.9ns@5V,50pF
- Input Logic Level - Low
- 500mV~1.65V
- Input Logic Level - High
- 1.5V~3.85V
- Operating Temperature
- -55℃~+125℃
- Output Logic Level - High
- 1.9V~2V;2.9V~3V;4.4V~4.5V;3.8V
- Quiescent Current(Iq)
- 1uA
- Current - Output High(IOH)
- 8mA
- Number of Channels
- 1;2
- Current - Output Low(IOL)
- 8mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.033 g
Overview
The SN74AHC1G08 is a single 2- input positive- AND gate. The device performs the Boolean function Y = A • B or Y = A(overline) + B(overline)(overline) in positive logic.
Key features
- Operating Range 2 - V to 5.5 - V
- Max tpd of 7 ns at 5 - V
- Low Power Consumption, 10 - μA Max ICC
- ±8 - mA Output Drive at 5 - V
- Schmitt - Trigger Action at All Inputs Makes the Circuit Tolerant for Slower Input Rise and Fall Time
- Latch - Up Performance Exceeds 250 mA Per JESD 17
- ESD Protection Exceeds JESD 22
- 2000 - V Human - Body Model (A114 - A)
- 200 - V Machine Model (A115 - A)
- 1000 - V Charged - Device Model (C101)
