TOSHIBADatasheet (PDF)
TC75S51FUTE85LF
1 2mV 500V/ms 65dB 1pA 600kHz 60uA SSOP-5-1.25mm Instrumentation, Op Amps, Buffer Amps RoHS
SSOP-5-1.25mmROHS3 CompliantActive
Low-Voltage Low-Power Single Operational Amplifier
- Manufacturer
- TOSHIBA
- Manufacturer part #
- TC75S51FUTE85LF
- Store part #
- C2058714
- Package / case
- SSOP-5-1.25mm
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,345 in stock
#C2058714
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹25.18 | ₹125.90 |
| 50+ | ₹21.99 | ₹1,099.50 |
| 150+ | ₹20.61 | ₹3,091.50 |
| 500+ | ₹18.91 | ₹9,455.00 |
| 3,000+ | ₹18.15 | ₹54,450.00 |
| 6,000+ | ₹17.69 | ₹1,06,140.00 |
5 × ₹25.18
₹125.90
excl. GST
₹148.56 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
TC75S51FUTE85LF
₹125.90 for 5 + GST
Specifications
- Number of Channels
- 1
- Vos - Input Offset Voltage
- 2mV
- Slew Rate
- 500V/ms
- Input Offset Current(Ios)
- 1pA
- Operating Temperature
- -40℃~+85℃
- Common Mode Rejection Ratio(CMRR)
- 65dB
- Ib - Input Bias Current
- 1pA
- Gain Bandwidth Product
- 600kHz
- Quiescent Current
- 60uA
- Features
- Built-in compensation
- Single Supply
- 1.5V~7V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.025 g
Overview
The TC75S51F/TC75S51FU is a CMOS single-operation amplifier which incorporates a phase compensation circuit. It is designed with a low-voltage and low-current power supply; this differentiates this device from general-purpose bipolar op-amps.
Key features
- Low-voltage operation : VDD = ±0.75 to ±3.5 V or 1.5 to 7 V
- Low-current power supply : IDD (VDD = 3 V) = 60 μA (typ.)
- Built-in phase-compensated op-amp, obviating the need for any external device
- Ultra-compact package
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | TSV6391ICT#C2057798ST · SC-70-5 | ST | SC-70-5 | 25 | ₹275.83 · 25 in stock | View |
 | TSV6391ICT(UMW)#C22374963UMW · SC-70-5 | UMW | SC-70-5 | 2,965 | ₹28.46 · 2,965 in stock | View |
 | TSV6391AICT(UMW)#C22374964UMW · SC-70-5 | UMW | SC-70-5 | 2,845 | ₹28.46 · 2,845 in stock | View |
 | HGV6001M7/TR#C53311458HGSEMI · SOT-353 | HGSEMI | SOT-353 | 3,000 | ₹14.63 · 3,000 in stock | View |
 | MCP6001M7/TR-HG#C53311459HGSEMI · SOT-353 | HGSEMI | SOT-353 | 2,975 | ₹14.78 · 2,975 in stock | View |
