TECH PUBLICDatasheet (PDF)
TC7SH126F-TP
2V~5.5V 1 1 4.5ns@3.3V,50pF SOT-23-5 Buffers, Drivers, Receivers, Transceivers
SOT-23-5RoHSActive
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- TC7SH126F-TP
- Store part #
- C54195015
- Package / case
- SOT-23-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,000 in stock
#C54195015
Stock & price checked 24 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹5.81 | ₹58.10 |
| 100+ | ₹4.58 | ₹458.00 |
| 300+ | ₹3.97 | ₹1,191.00 |
| 3,000+ | ₹3.51 | ₹10,530.00 |
| 6,000+ | ₹3.14 | ₹18,840.00 |
| 9,000+ | ₹2.95 | ₹26,550.00 |
10 × ₹5.81
₹58.10
excl. GST
₹68.56 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
TC7SH126F-TP
₹58.10 for 10 + GST
Specifications
- Current - Output High(IOH)
- 32mA
- Series
- TC7SH
- Voltage - Supply
- 2V~5.5V
- Output Type
- Tri-State
- Current - Output Low(IOL)
- 32mA
- Number of Bits per Element
- 1
- Channel Type
- Unidirectional
- Number of Elements
- 1
- Operating Temperature
- -40℃~+125℃
- Quiescent Supply Current
- 10uA
- Propagation Delay
- 4.5ns@3.3V,50pF
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.035 g
Overview
The TC7SH126 is a single bus buffer gate. The device is designed for Vcc operation from 2 V to 5.5 V and can be driven by 3.3 V or 5 V devices. This feature allows these devices to be used as translators in mixed 3.3 V and 5 V environments. The TC7SH126 is a single line driver with tri-state outputs. When the output enable input is low, the output is disabled. The TC7SH126 is available in SOT23-5 and SOT353 packages.
Applications
- Cable modem termination systems
- High-speed data acquisition and generation
- Motor control: high voltage
- Power line communication modems
- Solid-state drives: internal or external
- Video broadcast and infrastructure: scalable platforms
- Video broadcast: IP-based multi-format transcoders
- Video communication systems
Key features
- Wide supply voltage range: 2 V to 5.5 V
- Maximum propagation delay TpD of 4.5 ns at Vcc = 3.3 V
- Low power consumption, maximum Icc of 10 μA
- Output drive current of ±24 mA at Vcc = 3.3 V
- Latch-up performance exceeds 100 mA per JESD 78 Class II
- ESD protection exceeds JESD 22
- HBM ESD 2000 V (A114-A)
- CDM ESD 1000 V (C101)
- Operating temperature range: -40°C to 125°C
- Available packages: SOT23-5 and SOT353
