HXV8542DGKRG
Standard (General Purpose) Amplifier 2 Circuit Rail-to-Rail Input, Rail-to-Rail Output MSOP-8
MSOP-8ROHS CompliantActive
Single-supply rail-to-rail input and output amplifier
- Manufacturer
- HANSCHIP semiconductor
- Manufacturer part #
- HXV8542DGKRG
- Store part #
- C19723790
- Package / case
- MSOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,965 in stock
#C19723790
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹18.57 | ₹92.85 |
| 50+ | ₹16.15 | ₹807.50 |
| 150+ | ₹15.11 | ₹2,266.50 |
| 500+ | ₹13.81 | ₹6,905.00 |
| 3,000+ | ₹13.23 | ₹39,690.00 |
| 6,000+ | ₹12.89 | ₹77,340.00 |
5 × ₹18.57
₹92.85
excl. GST
₹109.56 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
HXV8542DGKRG
₹92.85 for 5 + GST
Specifications
- Output Current
- 15mA
- Number of Channels
- 2
- Vos - Input Offset Voltage
- 1mV
- Slew Rate
- 750V/ms
- Input Offset Current(Ios)
- 0.1pA
- Operating Temperature
- -40℃~+125℃
- Ib - Input Bias Current
- 4pA
- Common Mode Rejection Ratio(CMRR)
- 45dB
- Input Offset Voltage Drift(Vos TC)
- 4uV/℃
- Quiescent Current
- 45uA
- Gain Bandwidth Product
- 980kHz
- Features
- Built-in compensation
- Input Voltage Noise Density
- 40nV/√Hz@1kHz
- Rail to Rail
- Rail-to-Rail Input, Rail-to-Rail Output
- Single Supply
- 2.7V~5.5V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.187 g
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | HX8632IDGKRG#C2977119HANSCHIP semiconductor · MSOP-8 | HANSCHIP semiconductor | MSOP-8 | 2,180 | ₹21.43 · 2,180 in stock | View |
 | LMV822DGKRG#C19723763HANSCHIP semiconductor · MSOP-8 | HANSCHIP semiconductor | MSOP-8 | 2,870 | ₹35.19 · 2,870 in stock | View |
| LMV358AIDGKRG#C49451911HANSCHIP semiconductor · MSOP-8 | HANSCHIP semiconductor | MSOP-8 | 4,720 | ₹8.31 · 4,720 in stock | View | |
 | LMV722DGKRG#C19723758HANSCHIP semiconductor · MSOP-8 | HANSCHIP semiconductor | MSOP-8 | 2,075 | ₹17.90 · 2,075 in stock | View |
| NJM4560DGKRG#C41378788HANSCHIP semiconductor · MSOP-8 | HANSCHIP semiconductor | MSOP-8 | 2,950 | ₹16.89 · 2,950 in stock | View | |
