JSMSEMIDatasheet (PDF)
SP3232EEN
3V~5.5V Transceiver 250Kbps SOP-16 Drivers, Receivers, Transceivers RoHS
SOP-16ROHS CompliantActive
SP3232EEN SEMICONDUCTOR
- Manufacturer
- JSMSEMI
- Manufacturer part #
- SP3232EEN
- Store part #
- C6396155
- Package / case
- SOP-16
- Category
- Drivers, Receivers, Transceivers
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
28,640 in stock
#C6396155
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹39.88 | ₹199.40 |
| 50+ | ₹31.12 | ₹1,556.00 |
| 150+ | ₹27.36 | ₹4,104.00 |
| 500+ | ₹22.66 | ₹11,330.00 |
| 2,500+ | ₹20.59 | ₹51,475.00 |
| 5,000+ | ₹19.33 | ₹96,650.00 |
5 × ₹39.88
₹199.40
excl. GST
₹235.29 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
SP3232EEN
₹199.40 for 5 + GST
Specifications
- Voltage - Supply
- 3V~5.5V
- Type
- Transceiver
- Data Rate
- 250Kbps
- Operating Temperature
- 0℃~+70℃
- ESD Protect
- ±8kV
- charge pump
- Yes
- Number of Drivers
- 2
- Features
- Automatic level shifting;Short-Circuit Protection
- Number of Receivers
- 2
- Quiescent Supply Current
- 0.3mA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.279 g
Overview
The SP3232EEN features two receivers, two drivers, and a dual charge pump circuit. The device complies with TIA/EIA-232-F standard requirements, providing an electrical interface between asynchronous communication controllers and serial port connectors. The charge pump and four small external capacitors enable operation from a single supply of 3.0V to 5.5V. The device supports data signaling rates up to 250kbit/s, with a maximum driver output slew rate of 35V/μs. Package: SOP-16.
Key features
- ESD protection on RS-232 I/O pins exceeds ±8KV (HBM)
- Compliant with TIA/EIA-232-F and ITU V.28 standards
- Operates from 3.0V to 5.5V Vcc supply
- Data rate up to 250kbit/s
- Two drivers and two receivers
- External capacitors: 4×0.1μF
- Accepts 5.0V logic inputs with 3.3V supply
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | MAX3232IDR-JSM#C41382480JSMSEMI · SOP-16 | JSMSEMI | SOP-16 | 505 | ₹41.99 · 505 in stock | View |
 | MAX3232CSE+T-JSM#C7529465JSMSEMI · SOP-16 | JSMSEMI | SOP-16 | 1,766 | ₹46.50 · 1,766 in stock | View |
 | MAX3232ESE+T-JSM#C33960114JSMSEMI · SOP-16 | JSMSEMI | SOP-16 | 2,565 | ₹42.55 · 2,565 in stock | View |
 | MAX232ESE+T-JSM#C41421781JSMSEMI · SOP-16 | JSMSEMI | SOP-16 | 2,110 | ₹47.42 · 2,110 in stock | View |
 | MAX3232EIDR-JSM#C46596311JSMSEMI · SOP-16 | JSMSEMI | SOP-16 | 3,260 | ₹41.62 · 3,260 in stock | View |
